| Item | NH50-450 | NH50-450 | NH50-450 |
| Voltage | DC24V/48V | DC24V/48V | DC24V/48V |
| Power | 800W | 1000W | 1200W |
| Displacement | 0.38cc | 0.6cc | 0.88cc |
| Stroke | 450mm | 450mm | 450mm |
| Top of the lift | 3.7T | 3.3T | 2.7T |
| Retraction force | 2T | 2T | 2T |
| Load speed | 10-11mm/s | 16-17mm/s | 23-24mm/s |
| Temperature | -30~70°C | -30~70°C | -30~70°C |
| Frequency | 6min/each time | 6min/each time | 6min/each time |
| Waterproof rate | IPX5 | IPX5 | IPX5 |
| Weight of cylinder per 10 CM stroke | 1.47KG | ||
| Packing Size | |||
