| Item | TG20-485 | TG20-485+ |
| Voltage | DC220V/DC12V/24V/48V | DC220V/DC24V/48V |
| Power | 300W | 800W |
| Stroke | 485mm | 485mm |
| Top of the lift | 400KG | 400KG |
| Retraction force | 110KG | 110KG |
| Load speed | 26-30mm/s | 50-58mm/s |
| Temperature | -30~70°C | -30~70°C |
| Frequency | 4min/each time | 6min/each time |
| Waterproof rate | IPX6 | IPX6 |
| N.W/G.W | 6.7KG/7.2KG | 7.7KG/8.2KG |
| Packing Size | 80X20X13CM | 80X20X13CM |
