| Item | TG40-500 | TG40-500+ |
| Voltage | DC220V/DC12V/24V/48V | DC220V/DC24V/48V |
| Power | 300W | 800W |
| Stroke | 500mm | 500mm |
| Top of the lift | 1.8T | 1.8T |
| Retraction force | 1T | 1T |
| Load speed | 7-8mm/s | 15-18mm/s |
| Temperature | -30~70°C | -30~70°C |
| Frequency | 4min/each time | 6min/each time |
| Waterproof rate | IPX6 | IPX6 |
| N.W/G.W | 10.9KG/11.4KG | 11.9KG/12.4KG |
| Packing Size | 80X23X15CM | 80X23X15CM |
