| Item | NH40-500 | NH40-500 | NH40-500 |
| Voltage | DC24V/48V | DC24V/48V | DC24V/48V |
| Power | 800W | 1000W | 1200W |
| Displacement | 0.38cc | 0.6cc | 0.88cc |
| Stroke | 500mm | 500mm | 500mm |
| Top of the lift | 2.3T | 2.1T | 1.7T |
| Retraction force | 1.3T | 1.3T | 1.3T |
| Load speed | 16-18mm/s | 25-27mm/s | 36-38mm/s |
| Temperature | -30~70°C | -30~70°C | -30~70°C |
| Frequency | 6min/each time | 6min/each time | 6min/each time |
| Waterproof rate | IPX5 | IPX5 | IPX5 |
| N.W/G.W | 13.1KG/13.6KG | ||
| Packing Size | 80X23X15CM |
